[Trouble Shooting] TD1300 Internal TPMS
TD1300 Internal TPMS Trouble Shooting
1. Indications disappear from / do not appear in the display.
A. Please make sure if monitor has battery inserted.
B. Be sure the power of battery is enough.
C. Be sure to observe the correct polarity when installing the batteries.
D. If you use power cord, make sure if it is disconnected.
E. Please make sure if battery has no power after use for a long time.
Battery could run out of power and we suggest to replace with new battery.
F. Please make sure if the system is in ‘sleeping mode’ as the ‘sleeping mode’ will
be triggered when system has been in idle for more than 15 minutes. It is for
power-saving purpose. You can let system back to work by shocking monitor
slightly or by pressing any of buttons in monitor.
G. If these solutions do not help improving the situation, consult your nearest
Tyredog dealer.
2. No connection between sensors and monitor. The status will show as chart below.
A. Please make sure if sensors are in a configured distance. This system,
TD1300A-I, should be applied in passenger car. If installed in other kind of
vehicle, the system doesn’t guarantee its functionality.
B. Battery has no power after use for a long time. Battery could run out of power.
C. Please make sure if your sensor has mixed with other systems’. As each sensor
has its unique identified number and monitor can only receivepre-loaded
identified number and cannot accept other new identifiednumber.
D. If these solutions do not help improve the situation, consult your nearest
Tyredog dealer.
3. Monitor can not stop beep.
When battery-lower indicator is on and keeps on running system for days straight,
it could make monitor abnormal and keep on beeping. Just change battery for back
to normal operation.
4. Monitor display color is getting dark
When car temperature is over 85℃, it is natural that LCD panel will be getting dark.
When car temperature is back to normal, LCD panel will be normal as well。
5. When temperature is below -25℃, the response time could be slower in LCD
monitor.
6. Monitor in the ‘sleeping mode’.
Temporarily park car or drive car in a stable speed, which could let monitor get into
‘sleeping mode’. It is a special design for power-saving purpose. You can simply
slightly shock monitor or press any of buttons to wake it up.
7. Please make sure the surface of glass is clean and flat to give the best fitness to
monitor bracket. Otherwise, the monitor could drop off.
Tire pressure will be always changing by many environmental factors.
8. Relearning function
The learning mode can only operate with new learning sensor.
9. As a result of changes inside tire temperature, tire pressure will cause changes in
the number of PSI.
10. This product is only one-year warranty.
